Description
Inheriting the classics and striving for new heights of excellence
The legendary "Vortex-Genie" you trust is now part of OHAUS! As a global leader in instruments and equipment, we assure you that the performance and quality of the Vortex-Genie will remain exceptional, and we will continuously strive to provide you with an outstanding experience. Additionally, we will empower this legend with the OHAUS advantages of Trust, Agility, Ingenuity, and Commitment, offering you greater value and superior products.
Applications
Reagent Mixing, Pellet Resuspension, Powder Dissolution, Sample Homogenization, Solution Blending, Suspension Preparation, Chemical Agitation, DNA/RNA Mixing, Protein Vortexing, PCR Setup, Buffer Preparation, Liquid Emulsification, Enzyme Reaction Mixing
Display
Adjustment knob(s) with dial markings for analog models, or LED displays for digital models.
Operation
Supports 100 VAC, 120 VAC, and 230 VAC power inputs, power cord included.
Communication
N/A
Construction
Zinc-casted housing with "no-walking feet" design, pop-off cup, 3-inch platform with rubber cover.
Design Features
Hands-free or touch on control, countdown timer, cold room and incubator compatible. Specially configured model for the applied biosystems protocol, featuring an attachment for holding half-skirted and unskirted PCR plates.
Specifications
|
Control |
Digital |
|
Orbit |
3.5 mm |
|
Dimensions |
165 mm x 165 mm x 122 mm (LxHxW) |
|
Timer |
1 s - 99 s ; 1 min - 99 min |
|
Speed Range |
500 rpm – 2,850 rpm |
|
Net Weight |
4 kg |
|
Safety Certification |
CE |
|
Power |
230V, 0.5A, 50Hz |
|
Accessories Included |
Pop-off Cup; 3-inch Platform |
|
Working Environment |
0°C - 38°C, 95%RH, non-condensing |
